WINX MOUNT Ultra Full Motion TV Bracket

WINX MOUNT Ultra Full Motion TV Bracket

R 799.00
VAT included.
OUT OF STOCK
QUICK INFO

Product Name: WINX MOUNT Ultra Full Motion TV Bracket
Product Type: Full Motion TV Wall Mount
Screen Size Compatibility: 37 – 80 inch
Maximum Load Capacity: 50 kg
VESA Compatibility: 200 × 200 mm to 600 × 400 mm
Tilt Range: -15° to +5°
Swivel Range: ±60°
Profile Distance (Wall): 70 – 650 mm

PRODUCT DESCRIPTION

The WINX MOUNT Ultra Full Motion TV Bracket is a robust wall mounting solution designed for larger televisions ranging from 37 to 80 inches. Built from heavy-duty steel, it supports displays weighing up to 50 kg, providing a secure and stable installation for modern home entertainment systems.

Its dual-arm full motion design allows for flexible positioning, with tilt adjustment from -15° to +5° and swivel capability of up to ±60°, enabling optimal viewing angles and glare reduction. The extended reach from 70 mm to 650 mm allows the TV to be positioned close to the wall or extended outward for better visibility.

Supporting a wide range of VESA mounting patterns from 200 × 200 mm to 600 × 400 mm, this bracket is compatible with most LED, LCD, OLED, and QLED televisions. A built-in ±3° level adjustment ensures accurate alignment after installation, making it a practical and versatile mounting solution for larger screen setups.

GENERAL

Brand: WINX
Model: MOUNT Ultra Full Motion TV Bracket
Product Type: Full Motion TV Wall Mount
Colour: Black
Material: Steel
Finish: Powder-Coated

COMPATIBILITY

Screen Size Compatibility: 37 – 80 inch
VESA Mount Compatibility: 200 × 200 mm, 300 × 300 mm, 400 × 400 mm, 600 × 400 mm
Supported Displays: LED, LCD, OLED, QLED Televisions

LOAD CAPACITY

Maximum Supported Weight: 50 kg

MOTION & ADJUSTMENT

Tilt Range: -15° to +5°
Swivel Range: ±60°
Extension Range from Wall: 70 – 650 mm
Rotation Adjustment: ±3° Level Adjustment

MOUNTING

Mount Type: Wall Mount
Mount Pattern: VESA Standard
Installation Type: Solid Wall or Stud Mounting

BUILD & DESIGN

Construction Material: Heavy-Duty Steel
Arm Type: Dual Arm Full Motion

PACKAGING

Weight    8200 g
Dimensions    74 × 7 × 37 cm

WHATS IN THE BOX

TV Wall Mount Bracket
Mounting Arms
Wall Plate
Installation Hardware Kit
Mounting Screws and Bolts
Wall Anchors
Installation Guide

WARRANTY

Warranty: Limited Manufacturer Warranty
